Factory Customized China PVC True Union Ball Valve with Socket or Threaded Joint End

Short Description:

Size	1/4 “ - 4 ”
Pressure	1000 PSI, 2000 PSI
End Connection	NPT, BSP, BSPT,BW,SW
Bore	Standard Bore
Body Material	CF8M (SS316), CF8 (SS304),WCB
Ball Material	CF8M (SS316), CF8 (SS304),F304,F316
Seat Material	PTFE, RPTFE, PEEK,NYLON,PPL
Design	ASME B16.34
Face to Face	Manufacturer Standard
Threaded Connection	ANSI B1.20.1
Weld Connection	ANSI B16.11
Checking & Test	API 598
Pressure-Temperature	ASME B16.34
Operation	By Lever ,By Electrical Actuator ,By Pneumatic Actuator
Temperature	-20℃ – 200℃ (Depend on Seat Material)

Send email to us

Product Detail

Product Tags

All we do is always associated with our tenet ” Customer first, Trust first, devoting on the food packaging and environmental protection for Factory Customized China PVC True Union Ball Valve with Socket or Threaded Joint End, Our business is dedicated to giving customers with significant and secure top quality products at aggressive price, making each and every customer pleased with our services.
All we do is always associated with our tenet ” Customer first, Trust first, devoting on the food packaging and environmental protection for China Ball Valve, Plastic Valve, The best and original quality for spare parts is a most important factor for transportation. We may stick on supplying original and good quality parts even a little profit earned. God will bless us to do kindness business forever.

Standard Material Specification

Dimensions and Weights (Unit:mm)

SIZE	DN(mm)	d	d1	d2	S	D	D1	L	H	W
1/4”	8	10.5	11.6	11.6	14.3	22.6	17	50	55	98
3/8”	10	12	12.7	12.7	17.8	22.6	17	60	55	98
1/2”	15	15	15	16	22.2	27.3	21.3	70	56	100
3/4”	20	20	20	20	27.7	33.1	26.7	80	62	115
1”	25	25	25	25	34.5	39.8	33.6	88	77	125
1-1/4”	32	32	32	33.8	43.2	48.6	42.4	100	82	140
1-1/2”	40	38	38	39.5	49.1	55.1	48	110	95	160
2”	50	50	50	50.8	61.1	68.1	60.5	135	100	165
2-1/2”	65	65	65	62.7	77.1	85.9	76.1	180	120	215
3”	80	80	80	77.9	90.0	100.8	88.9	190	125	220
4”	100	100	100	100	115.5	127.5	114.2	235	150	250

Advantage

1.Made of investment casting for the body of 3-PC ISO 5211 Pad Ball Valve
2.Factory supplied with competitive price
3.All the test reports offered before shipment for approved
4.100% testing before shipment and ensure 0 leakage for 3-PC ISO 5211 Pad Ball Valve

Technical Drawing for 2000PSI 3PC Ball Valve

certificate
All we do is always associated with our tenet ” Customer first, Trust first, devoting on the food packaging and environmental protection for Factory Customized China PVC True Union Ball Valve with Socket or Threaded Joint End, Our business is dedicated to giving customers with significant and secure top quality products at aggressive price, making each and every customer pleased with our services.
Factory Customized China Ball Valve, Plastic Valve, The best and original quality for spare parts is a most important factor for transportation. We may stick on supplying original and good quality parts even a little profit earned. God will bless us to do kindness business forever.
